Death Star Security¶

master yeoda

a long long time ago in a galaxy far far away

Back to the Spell Book

1. Libraries¶

In [1]:
import pandas as pd
import numpy as np
from sklearn.model_selection import train_test_split
from sklearn.tree import DecisionTreeClassifier, plot_tree
from sklearn.metrics import confusion_matrix, classification_report, roc_curve, auc
import matplotlib.pyplot as plt
import seaborn as sns

2. Load data¶

Classifying whether a login attempt is fraudulent.

  • IP_location_known: 1 = Yes, 0 = No
  • number_of_attempts: Number of login attempts
  • browser_security: 1 = Yes, 0 = No
  • fraudulent: 1 = Yes, 0 = No
  • time_of_day_24: The hour in 24-hour format
In [2]:
login = pd.read_csv("login.csv")
login.head()
Out[2]:
IP_location_known number_of_attempts browser_security fraudulent time_of_day_24
0 1 3 1 0 4
1 1 2 1 0 6
2 1 1 1 0 19
3 0 3 0 1 4
4 0 2 0 1 4
In [3]:
login.shape
Out[3]:
(1000, 5)
In [4]:
login["fraudulent"].value_counts()
Out[4]:
0    770
1    230
Name: fraudulent, dtype: int64

Data types

In [5]:
login.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 1000 entries, 0 to 999
Data columns (total 5 columns):
 #   Column              Non-Null Count  Dtype
---  ------              --------------  -----
 0   IP_location_known   1000 non-null   int64
 1   number_of_attempts  1000 non-null   int64
 2   browser_security    1000 non-null   int64
 3   fraudulent          1000 non-null   int64
 4   time_of_day_24      1000 non-null   int64
dtypes: int64(5)
memory usage: 39.2 KB

Convert relevant columns to categorical (equivalent to factor in R).

In [6]:
categorical_columns = ["IP_location_known", "browser_security", "fraudulent"]
login[categorical_columns] = login[categorical_columns].astype('category')

3. Training-Validation¶

In [7]:
train_df, valid_df = train_test_split(login, test_size=0.3, random_state=666)

4. Decision Tree¶

Train the tree

In [8]:
X_train = train_df[["IP_location_known", "number_of_attempts", "time_of_day_24", "browser_security"]]
y_train = train_df["fraudulent"]

clf = DecisionTreeClassifier(max_depth=3, random_state=666)
clf.fit(X_train, y_train)
Out[8]:
DecisionTreeClassifier(max_depth=3, random_state=666)

4.1 Plot¶

In [9]:
plt.figure(figsize=(12, 8))
plot_tree(clf, feature_names=X_train.columns, class_names=["0", "1"], filled=True)
plt.show()

4.2 Model Evaluation¶

4.2.1 Training¶

In [10]:
y_train_pred = clf.predict(X_train)
conf_matrix_train = confusion_matrix(y_train, y_train_pred)
print(conf_matrix_train)
print(classification_report(y_train, y_train_pred))

[[493  51]
 [ 22 134]]
              precision    recall  f1-score   support

           0       0.96      0.91      0.93       544
           1       0.72      0.86      0.79       156

    accuracy                           0.90       700
   macro avg       0.84      0.88      0.86       700
weighted avg       0.91      0.90      0.90       700
In [11]:
from sklearn.metrics import confusion_matrix, ConfusionMatrixDisplay
import matplotlib.pyplot as plt

confusion_matrix_train_display = ConfusionMatrixDisplay(conf_matrix_train, display_labels = clf.classes_)
confusion_matrix_train_display.plot()
plt.grid(False)

4.2.2 Validation¶

In [12]:
X_valid = valid_df[["IP_location_known", "number_of_attempts", "time_of_day_24", "browser_security"]]
y_valid = valid_df["fraudulent"]

y_valid_pred = clf.predict(X_valid)
conf_matrix_valid = confusion_matrix(y_valid, y_valid_pred)
print(conf_matrix_valid)
print(classification_report(y_valid, y_valid_pred))

[[197  29]
 [  8  66]]
              precision    recall  f1-score   support

           0       0.96      0.87      0.91       226
           1       0.69      0.89      0.78        74

    accuracy                           0.88       300
   macro avg       0.83      0.88      0.85       300
weighted avg       0.90      0.88      0.88       300
In [13]:
# from sklearn.metrics import confusion_matrix, ConfusionMatrixDisplay
# import matplotlib.pyplot as plt

confusion_matrix_valid_display = ConfusionMatrixDisplay(conf_matrix_valid, display_labels = clf.classes_)
confusion_matrix_valid_display.plot()
plt.grid(False)

Probabilities for Validation Set Predictions¶

In [14]:
y_valid_prob = clf.predict_proba(X_valid)
y_valid_prob[:5]
Out[14]:
array([[1.        , 0.        ],
       [1.        , 0.        ],
       [0.36538462, 0.63461538],
       [0.        , 1.        ],
       [0.79816514, 0.20183486]])

ROC Curve¶

In [15]:
fpr, tpr, _ = roc_curve(y_valid.cat.codes, y_valid_prob[:, 1])
roc_auc = auc(fpr, tpr)
print(f"AUC: {roc_auc}")

plt.figure(figsize=(8, 6))
plt.plot(fpr, tpr, label=f"ROC curve (area = {roc_auc:.2f})")
plt.plot([0, 1], [0, 1], "k--")
plt.xlabel("False Positive Rate")
plt.ylabel("True Positive Rate")
plt.title("ROC Curve")
plt.legend(loc="lower right")
plt.show()

AUC: 0.9338973929681894

5. New Data¶

5.1 Import¶

Get new data on 3 login attempts for classification

In [16]:
new_login = pd.read_csv("new_login.csv")
new_login.head()
Out[16]:
IP_location_known number_of_attempts browser_security time_of_day_24
0 0 2 1 17
1 1 3 0 3
2 0 1 0 5

Convert relevant columns to categorical.

In [17]:
new_login[categorical_columns[:-1]] = new_login[categorical_columns[:-1]].astype("category")

5.2 Predict¶

In [18]:
new_login_pred = clf.predict(new_login[["IP_location_known", "number_of_attempts",
                                        "time_of_day_24", "browser_security"]])
new_login_prob = clf.predict_proba(new_login[["IP_location_known", "number_of_attempts",
                                              "time_of_day_24", "browser_security"]])

new_login["Prediction"] = new_login_pred
new_login["Probability"] = new_login_prob[:, 1]
new_login
Out[18]:
IP_location_known number_of_attempts browser_security time_of_day_24 Prediction Probability
0 0 2 1 17 0 0.000000
1 1 3 0 3 0 0.201835
2 0 1 0 5 1 0.741935

Use the force on the Death Star :-)
